Press Tableting Machine
Press Tableting Machine
Description
Tablet press machine Product manual
|
Model |
TDP-1.5T |
TDP-5T |
TDP-6T |
|
Max.Pressure |
15KN |
50KN |
60KN |
|
Max.Tablet Diameter |
4-12mm/0.15”-0.47” |
4-20mm/0.15”-0.8” |
4-25mm/0.15”-0.98” |
|
Max.Tablet Thickness |
6mm/0.24” |
6-8mm/0.24”-0.31” |
|
|
Max.Filling Depth |
12mm/0.47” |
16mm/0.63” |
|
|
Production Capacity |
4500-6000pcs/hour |
3000-4000pcs/hour |
|
|
Weight |
50kg |
130kg |
145kg |
|
Dimension |
700*370*800mm |
700*400*800mm |
700*500*900mm |
|
Motor Speed |
1400r/min |
||
|
Motor Power |
370w |
750w |
1100w |
Additional explanation
In order to facilitate transportation, let the tablet press pass through customs as soon as possible to reduce transportation time. We will disassemble the machine into two parts and ship by express. To ensure that the goods can reach the delivery address smoothly, we will provide assembly videos to facilitate self-assembly after arrival.
